Stock #  HG1030M+5DT

Rainbow 30' + 5' DT Gooseneck Deck Over Trailer - Express w/ 2-12000 lbs. Axles

  • Rainbow 30' + 5' DT Gooseneck Deck Over Trailer Express w/ 2 12000 lbs. Axles
  • Rainbow 30' + 5' DT Gooseneck Deck Over Trailer Express w/ 2 12000 lbs. Axles
  • Rainbow 30' + 5' DT Gooseneck Deck Over Trailer Express w/ 2 12000 lbs. Axles
  • Rainbow 30' + 5' DT Gooseneck Deck Over Trailer Express w/ 2 12000 lbs. Axles
  • Rainbow 30' + 5' DT Gooseneck Deck Over Trailer Express w/ 2 12000 lbs. Axles
  • Rainbow 30' + 5' DT Gooseneck Deck Over Trailer Express w/ 2 12000 lbs. Axles
  • Rainbow 30' + 5' DT Gooseneck Deck Over Trailer Express w/ 2 12000 lbs. Axles
  • Rainbow 30' + 5' DT Gooseneck Deck Over Trailer Express w/ 2 12000 lbs. Axles
  • Rainbow 30' + 5' DT Gooseneck Deck Over Trailer Express w/ 2 12000 lbs. Axles
  • Rainbow 30' + 5' DT Gooseneck Deck Over Trailer Express w/ 2 12000 lbs. Axles
In Stock
Dealer Price $28,499 CAD
+GST & Doc Fee
 Get a Quote  Get Financed  Contact Us   Get Directions  Print
Overview

30' + 5' DT Gooseneck Deck Over Trailer - Express

$28,499 + GST & Doc Fee

Financing Available

- 2-12,000 lb Spring Straight Axle

- Brake Protection

- 2 x 44" Flip Over Spring Assist Ramps

- Dual 12K Jack

- Rub Rail

- Driver Side Toolbox

- Spare Tire

Specifications
Model
Heavy Deck Above Trailer 30
Category Name
Trailers
Year
2027
Manufacturer
Rainbow
Ply
10
GAWR
20,000 lbs
GVWR
20,000 lbs
Jack
2 – 12K
Axles
2 x 10000 lb
Floor
2″ Spruce
Tires
235/80/R16E
Brakes
Electric
Ball Size
2 5/16″
Crossmember
3″ Channel
Curb Weight
5,936 lbs
Deck Height
38″
Deck Length
30′
Available In
Express, Excursion
Bolt Pattern
8 – 6.5 Bolt
Hitch Height
31″ – 39″
Frame & Hitch
12″ x 19 lb. I-Beam
Overall Width
102″ (97″ Deck Width)
Overall Length
39′
Payload Capacity
17,064 lbs
Electrical Hook-up
RV Plug
Crossmember Spacing
16″
Hitch Weight (Empty)
1,719 lbs
express

STANDARD FEATURES

  • 2″ Painted spruce floor
  • Metal preparation by sandblasting
  • 2-Part epoxy primer
  • High quality black topcoat paint
  • Heavy duty stake pockets
  • Wiring enclosed in poly conduit

AVAILABLE OPTIONS – All

  • Spare tire
  • Spare tire holder
  • RV king pin
  • Upgrade to 2 speed jacks
  • 15″ x 96″ Slide in ramps (not available on dovetail trailers)
  • Under deck side toolbox
  • Rubrail
  • Tie down winch
  • D-rings
  • LED Lights
  • Bumber hitch (pintle ring or 2 5/16″ coupler)

AVAILABLE OPTIONS – 2 x 7,000 lb Axle

  • Upgrade to 7,000 lb torflex axles
  • Upgrade to tandem 8,000 lb. spring axles (16,000 lb. GVW)
  • Aluminum wheels
  • 5′ Dovetail with 2-20″ or 2-44″ spring assisted flip over ramps

AVAILABLE OPTIONS – 3 x 7,000 lb Axle

  • Upgrade to torflex axles
  • Upgrade to Tridem 8,000 lb. spring axles (24,000 lb. GVW)
  • Aluminum wheels
  • 5′ Dovetail with 2-20″ or 2-44″ spring assisted flip over ramps

AVAILABLE OPTIONS – 2 x 10,000 lb Axle

  • Upgrade to 12,000 lb. axles
  • 5′ Dovetail with 20″ or 44″ spring assisted flip over ramps
literature
Name Link
Heavy Deck Above Brochure                                                      Download
