Rainbow

Stock #  8P7T22M

Rainbow 22' + 2' Partial Tilt Trailer w/ 2-7000 lbs. Axles

Call for Price
+ GST & Doc Fee
Overview

22' + 2' Partial Tilt Equipment Trailer - Excursion

$12,499 +GST & Doc Fee

Financing Available

- 2-7000 lb Spring Straight Axles

- 15K Height Adjust Couple

- Smooth Fender

- Standard Wheel Mod Rim

Specifications
Model
Partial Tilting Trailer 22
Category Name
Trailers
Year
2026
Manufacturer
Rainbow
Ply
10 Ply
GVWR
14,000 lbs
Jack
12,000 lb Drop Leg
Axles
2-7000 lb
Floor
2″ Spruce
Tires
16″ E Range
Brakes
Both Axles
Coupler
2 5/16″ H/A
Ball Size
2 5/16″ H/A
Crossmember
3″ Channel
Curb Weight
3,085 lbs
Deck Height
23″ Torflex
Deck Length
18′ Plus 4′ Stat
Available In
Excursion
Bolt Pattern
8-65 Bolt
Hitch Height
20″
Frame & Hitch
6″ Channel
Overall Width
102″
Overall Length
27′ 10″
Between Fenders
81 1/2″
Payload Capacity
12,315 lbs
Electrical Hook-up
RV Plug
Crossmember Spacing
16″
Hitch Weight (Empty)
610 lbs
excursion

STANDARD FEATURES

PARITAL TILTING TRAILER
STANDARD FEATURES

  • 2″ painted spruce floor
  • 14,000 lb. GVWR – Tandem 7,000 lb. axles
  • 6″ Channel frame & hitch
  • 3″ Channel cross members
  • Metal preparation by sandblasting
  • 2-part epoxy primer
  • High quality black topcoat paint
  • Stoneguard protection
  • Silver graphics package
  • Front bump rail
  • Heavy duty stake pockets
  • LED lights
  • 9″ x 72″ Teardrop fenders with liner
  • Dovetail
  • Wiring enclosed in poly conduit
  • Gravity tilt with hydraulic cylinder
  • DOT Compliant safety chains

AVAILABLE OPTIONS

  • Spare tire
  • Spare tire holder
  • Aluminum wheel upgrade
  • Height adjustable pintle ring
  • Rub rail
  • D-rings
  • Upgrade to diamond plate fenders

FULL TILTING TRAILER
STANDARD FEATURES

  • 2″ painted spruce floor
  • 7,000 lb. GVWR – Tandem 3,500 lb. axles
  • 4-leaf double eye suspensions
  • 3″ channel cross members
  • Metal preparation by sandblasting
  • 2-part epoxy primer
  • High quality black topcoat paint
  • Stoneguard protection
  • Silver graphics package
  • Front bump rail
  • Heavy duty stake pockets
  • LED lights
  • 9″ x 72″ Teardrop fenders with liner
  • Dovetail
  • Wiring enclosed in poly conduit
  • Hydraulic jack for raising & lowering deck
  • DOT Compliant safety chains

AVAILABLE OPTIONS

  • 9,900 lb. GVWR – Tandem 5,200 lb. axles
  • 14,000 lb. GVWR – Tandem 7,000 lb. axles
  • Torflex axle upgrade
  • Spare tire
  • Spare tire holder
  • Aluminum wheel upgrade
  • 2 5/16″ Height-adjustable pintle ring
  • 2 5/16″ Height-adjustable ball coupler
  • Upgrade to 12K jack (9,900 lb. & 14,000 lb. GVWR trailer)
  • Rub rail
  • D-rings
  • Upgrade to diamond plate fenders
